Sto utilizzando la libreria Android WeekView. Per impostazione predefinita, l'intervallo di ore va da 0 a 24. Voglio mostrare solo la fascia di ore che vanno da 8 a 20. Ho modificato il codice della view, ma ora rimane spazio vuoto per le ore che non voglio vedere e non riesco ad impostare lo scroll in base agli orari disponibili...
Grazie per l'aiuto
public class WeekView extends View {
@Deprecated
public static final int LENGTH_SHORT = 1;
@Deprecated
public static final int LENGTH_LONG = 2;
private final Context mContext;
private Calendar mToday;
private Calendar mStartDate;
private Paint mTimeTextPaint;
private float mTimeTextWidth;
private float mTimeTextHeight;
private Paint mHeaderTextPaint;
private float mHeaderTextHeight;
private GestureDetectorCompat mGestureDetector;
private OverScroller mScroller;
private PointF mCurrentOrigin = new PointF(0f, 0f);
private Direction mCurrentScrollDirection = Direction.NONE;
private Paint mHeaderBackgroundPaint;
private float mWidthPerDay;
private Paint mDayBackgroundPaint;
private Paint mHourSeparatorPaint;
private float mHeaderMarginBottom;
private Paint mTodayBackgroundPaint;
private Paint mTodayHeaderTextPaint;
private Paint mEventBackgroundPaint;
private float mHeaderColumnWidth;
private List<EventRect> mEventRects;
private TextPaint mEventTextPaint;
private Paint mHeaderColumnBackgroundPaint;
private Scroller mStickyScroller;
private int mFetchedMonths[] = new int[3];
private boolean mRefreshEvents = false;
private float mDistanceY = 0;
private float mDistanceX = 0;
private Direction mCurrentFlingDirection = Direction.NONE;
private int mHourHeight = 50;
private int mColumnGap = 10;
private int mFirstDayOfWeek = Calendar.MONDAY;
private int mTextSize = 12;
private int mHeaderColumnPadding = 10;
private int mHeaderColumnTextColor = Color.BLACK;
private int mNumberOfVisibleDays = 3;
private int mHeaderRowPadding = 10;
private int mHeaderRowBackgroundColor = Color.WHITE;
private int mDayBackgroundColor = Color.rgb(245, 245, 245);
private int mHourSeparatorColor = Color.rgb(230, 230, 230);
private int mTodayBackgroundColor = Color.rgb(239, 247, 254);
private int mHourSeparatorHeight = 2;
private int mTodayHeaderTextColor = Color.rgb(39, 137, 228);
private int mEventTextSize = 14;
private int mEventTextColor = Color.BLACK;
private int mEventPadding = 8;
private int mHeaderColumnBackgroundColor = Color.WHITE;
private int mDefaultEventColor;
private boolean mIsFirstDraw = true;
private boolean mAreDimensionsInvalid = true;
@Deprecated private int mDayNameLength = LENGTH_LONG;
private int mOverlappingEventGap = 0;
private int mEventMarginVertical = 0;
private float mXScrollingSpeed = 1f;
private Calendar mFirstVisibleDay;
private Calendar mLastVisibleDay;
private Calendar mScrollToDay = null;
private double mScrollToHour = -1;
private EventClickListener mEventClickListener;
private EventLongPressListener mEventLongPressListener;
private MonthChangeListener mMonthChangeListener;
private EmptyViewClickListener mEmptyViewClickListener;
private EmptyViewLongPressListener mEmptyViewLongPressListener;
private DateTimeInterpreter mDateTimeInterpreter;
private final GestureDetector.SimpleOnGestureListener mGestureListener = new GestureDetector.SimpleOnGestureListener() {
@Override
public boolean onDown(MotionEvent e) {
mScroller.forceFinished(true);
mStickyScroller.forceFinished(true);
return true;
}
@Override
public boolean onScroll(MotionEvent e1, MotionEvent e2, float distanceX, float distanceY) {
if (mCurrentScrollDirection == Direction.NONE) {
if (Math.abs(distanceX) > Math.abs(distanceY)){
mCurrentScrollDirection = Direction.HORIZONTAL;
mCurrentFlingDirection = Direction.HORIZONTAL;
}
else {
mCurrentFlingDirection = Direction.VERTICAL;
mCurrentScrollDirection = Direction.VERTICAL;
}
}
mDistanceX = distanceX;
mDistanceY = distanceY;
invalidate();
return true;
}
@Override
public boolean onFling(MotionEvent e1, MotionEvent e2, float velocityX, float velocityY) {
mScroller.forceFinished(true);
mStickyScroller.forceFinished(true);
if (mCurrentFlingDirection == Direction.HORIZONTAL){
mScroller.fling((int) mCurrentOrigin.x, 0, (int) (velocityX * mXScrollingSpeed), 0, Integer.MIN_VALUE, Integer.MAX_VALUE, 0, 0);
}
else if (mCurrentFlingDirection == Direction.VERTICAL){
mScroller.fling(8, (int) mCurrentOrigin.y, 0, (int) velocityY, 0, 0, (int) -(mHourHeight * 13 + mHeaderTextHeight + mHeaderRowPadding * 2 - getHeight()), 0);
}
ViewCompat.postInvalidateOnAnimation(WeekView.this);
return true;
}
@Override
public boolean onSingleTapConfirmed(MotionEvent e) {
if (mEventRects != null && mEventClickListener != null) {
List<EventRect> reversedEventRects = mEventRects;
Collections.reverse(reversedEventRects);
for (EventRect event : reversedEventRects) {
if (event.rectF != null && e.getX() > event.rectF.left && e.getX() < event.rectF.right && e.getY() > event.rectF.top && e.getY() < event.rectF.bottom) {
mEventClickListener.onEventClick(event.originalEvent, event.rectF);
playSoundEffect(SoundEffectConstants.CLICK);
return super.onSingleTapConfirmed(e);
}
}
}
if (mEmptyViewClickListener != null && e.getX() > mHeaderColumnWidth && e.getY() > (mHeaderTextHeight + mHeaderRowPadding * 2 + mHeaderMarginBottom)) {
Calendar selectedTime = getTimeFromPoint(e.getX(), e.getY());
if (selectedTime != null) {
playSoundEffect(SoundEffectConstants.CLICK);
mEmptyViewClickListener.onEmptyViewClicked(selectedTime);
}
}
return super.onSingleTapConfirmed(e);
}
@Override
public void onLongPress(MotionEvent e) {
super.onLongPress(e);
if (mEventLongPressListener != null && mEventRects != null) {
List<EventRect> reversedEventRects = mEventRects;
Collections.reverse(reversedEventRects);
for (EventRect event : reversedEventRects) {
if (event.rectF != null && e.getX() > event.rectF.left && e.getX() < event.rectF.right && e.getY() > event.rectF.top && e.getY() < event.rectF.bottom) {
mEventLongPressListener.onEventLongPress(event.originalEvent, event.rectF);
performHapticFeedback(HapticFeedbackConstants.LONG_PRESS);
return;
}
}
}
if (mEmptyViewLongPressListener != null && e.getX() > mHeaderColumnWidth && e.getY() > (mHeaderTextHeight + mHeaderRowPadding * 2 + mHeaderMarginBottom)) {
Calendar selectedTime = getTimeFromPoint(e.getX(), e.getY());
if (selectedTime != null) {
performHapticFeedback(HapticFeedbackConstants.LONG_PRESS);
mEmptyViewLongPressListener.onEmptyViewLongPress(selectedTime);
}
}
}
};
private enum Direction {
NONE, HORIZONTAL, VERTICAL
}
public WeekView(Context context) {
this(context, null);
}
public WeekView(Context context, AttributeSet attrs) {
this(context, attrs, 0);
}
public WeekView(Context context, AttributeSet attrs, int defStyleAttr) {
super(context, attrs, defStyleAttr);
mContext = context;
TypedArray a = context.getTheme().obtainStyledAttributes(attrs, R.styleable.WeekView, 0, 0);
try {
mFirstDayOfWeek = a.getInteger(R.styleable.WeekView_firstDayOfWeek, mFirstDayOfWeek);
mHourHeight = a.getDimensionPixelSize(R.styleable.WeekView_hourHeight, mHourHeight);
mTextSize = a.getDimensionPixelSize(R.styleable.WeekView_textSize, (int) TypedValue.applyDimension(TypedValue.COMPLEX_UNIT_SP, mTextSize, context.getResources().getDisplayMetrics()));
mHeaderColumnPadding = a.getDimensionPixelSize(R.styleable.WeekView_headerColumnPadding, mHeaderColumnPadding);
mColumnGap = a.getDimensionPixelSize(R.styleable.WeekView_columnGap, mColumnGap);
mHeaderColumnTextColor = a.getColor(R.styleable.WeekView_headerColumnTextColor, mHeaderColumnTextColor);
mNumberOfVisibleDays = a.getInteger(R.styleable.WeekView_noOfVisibleDays, mNumberOfVisibleDays);
mHeaderRowPadding = a.getDimensionPixelSize(R.styleable.WeekView_headerRowPadding, mHeaderRowPadding);
mHeaderRowBackgroundColor = a.getColor(R.styleable.WeekView_headerRowBackgroundColor, mHeaderRowBackgroundColor);
mDayBackgroundColor = a.getColor(R.styleable.WeekView_dayBackgroundColor, mDayBackgroundColor);
mHourSeparatorColor = a.getColor(R.styleable.WeekView_hourSeparatorColor, mHourSeparatorColor);
mTodayBackgroundColor = a.getColor(R.styleable.WeekView_todayBackgroundColor, mTodayBackgroundColor);
mHourSeparatorHeight = a.getDimensionPixelSize(R.styleable.WeekView_hourSeparatorHeight, mHourSeparatorHeight);
mTodayHeaderTextColor = a.getColor(R.styleable.WeekView_todayHeaderTextColor, mTodayHeaderTextColor);
mEventTextSize = a.getDimensionPixelSize(R.styleable.WeekView_eventTextSize, (int) TypedValue.applyDimension(TypedValue.COMPLEX_UNIT_SP, mEventTextSize, context.getResources().getDisplayMetrics()));
mEventTextColor = a.getColor(R.styleable.WeekView_eventTextColor, mEventTextColor);
mEventPadding = a.getDimensionPixelSize(R.styleable.WeekView_hourSeparatorHeight, mEventPadding);
mHeaderColumnBackgroundColor = a.getColor(R.styleable.WeekView_headerColumnBackground, mHeaderColumnBackgroundColor);
mDayNameLength = a.getInteger(R.styleable.WeekView_dayNameLength, mDayNameLength);
mOverlappingEventGap = a.getDimensionPixelSize(R.styleable.WeekView_overlappingEventGap, mOverlappingEventGap);
mEventMarginVertical = a.getDimensionPixelSize(R.styleable.WeekView_eventMarginVertical, mEventMarginVertical);
mXScrollingSpeed = a.getFloat(R.styleable.WeekView_xScrollingSpeed, mXScrollingSpeed);
} finally {
a.recycle();
}
init();
}
private void init() {
mToday = Calendar.getInstance();
mToday.set(Calendar.HOUR_OF_DAY, 0);
mToday.set(Calendar.MINUTE, 0);
mToday.set(Calendar.SECOND, 0);
mGestureDetector = new GestureDetectorCompat(mContext, mGestureListener);
mScroller = new OverScroller(mContext);
mStickyScroller = new Scroller(mContext);
mTimeTextPaint = new Paint(Paint.ANTI_ALIAS_FLAG);
mTimeTextPaint.setTextAlign(Paint.Align.RIGHT);
mTimeTextPaint.setTextSize(mTextSize);
mTimeTextPaint.setColor(mHeaderColumnTextColor);
Rect rect = new Rect();
mTimeTextPaint.getTextBounds("00 PM", 0, "00 PM".length(), rect);
mTimeTextWidth = mTimeTextPaint.measureText("00 PM");
mTimeTextHeight = rect.height();
mHeaderMarginBottom = mTimeTextHeight / 2;
mHeaderTextPaint = new Paint(Paint.ANTI_ALIAS_FLAG);
mHeaderTextPaint.setColor(mHeaderColumnTextColor);
mHeaderTextPaint.setTextAlign(Paint.Align.CENTER);
mHeaderTextPaint.setTextSize(mTextSize);
mHeaderTextPaint.getTextBounds("00 PM", 0, "00 PM".length(), rect);
mHeaderTextHeight = rect.height();
mHeaderTextPaint.setTypeface(Typeface.DEFAULT_BOLD);
mHeaderBackgroundPaint = new Paint();
mHeaderBackgroundPaint.setColor(mHeaderRowBackgroundColor);
mDayBackgroundPaint = new Paint();
mDayBackgroundPaint.setColor(mDayBackgroundColor);
mHourSeparatorPaint = new Paint();
mHourSeparatorPaint.setStyle(Paint.Style.STROKE);
mHourSeparatorPaint.setStrokeWidth(mHourSeparatorHeight);
mHourSeparatorPaint.setColor(mHourSeparatorColor);
mTodayBackgroundPaint = new Paint();
mTodayBackgroundPaint.setColor(mTodayBackgroundColor);
mTodayHeaderTextPaint = new Paint(Paint.ANTI_ALIAS_FLAG);
mTodayHeaderTextPaint.setTextAlign(Paint.Align.CENTER);
mTodayHeaderTextPaint.setTextSize(mTextSize);
mTodayHeaderTextPaint.setTypeface(Typeface.DEFAULT_BOLD);
mTodayHeaderTextPaint.setColor(mTodayHeaderTextColor);
mEventBackgroundPaint = new Paint();
mEventBackgroundPaint.setColor(Color.rgb(174, 208, 238));
mHeaderColumnBackgroundPaint = new Paint();
mHeaderColumnBackgroundPaint.setColor(mHeaderColumnBackgroundColor);
mEventTextPaint = new TextPaint(Paint.ANTI_ALIAS_FLAG | Paint.LINEAR_TEXT_FLAG);
mEventTextPaint.setStyle(Paint.Style.FILL);
mEventTextPaint.setColor(mEventTextColor);
mEventTextPaint.setTextSize(mEventTextSize);
mStartDate = (Calendar) mToday.clone();
mDefaultEventColor = Color.parseColor("#9fc6e7");
}
@Override
protected void onDraw(Canvas canvas) {
super.onDraw(canvas);
drawHeaderRowAndEvents(canvas);
drawTimeColumnAndAxes(canvas);
canvas.drawRect(0, 0, mTimeTextWidth + mHeaderColumnPadding * 2, mHeaderTextHeight + mHeaderRowPadding * 2, mHeaderBackgroundPaint);
canvas.drawRect(mHeaderColumnWidth, mHeaderTextHeight + mHeaderRowPadding * 2, getWidth(), mHeaderRowPadding * 2 + mHeaderTextHeight + mHeaderMarginBottom + mTimeTextHeight/2 - mHourSeparatorHeight / 2, mHeaderColumnBackgroundPaint);
}
private void drawTimeColumnAndAxes(Canvas canvas) {
if (mCurrentScrollDirection == Direction.VERTICAL) {
if (mCurrentOrigin.y - mDistanceY > 0) mCurrentOrigin.y = 8;
else if (mCurrentOrigin.y - mDistanceY < -(mHourHeight * 13 + mHeaderTextHeight + mHeaderRowPadding * 2 - getHeight())) mCurrentOrigin.y = -(mHourHeight * 13 + mHeaderTextHeight + mHeaderRowPadding * 2 - getHeight());
else mCurrentOrigin.y -= mDistanceY;
}
canvas.drawRect(0, mHeaderTextHeight + mHeaderRowPadding * 2, mHeaderColumnWidth, getHeight(), mHeaderColumnBackgroundPaint);
for (int i = 8; i < 21; i++) {
float top = mHeaderTextHeight + mHeaderRowPadding * 2 + mCurrentOrigin.y + mHourHeight * i + mHeaderMarginBottom;
String time = getDateTimeInterpreter().interpretTime(i);
if (time == null)
throw new IllegalStateException("A DateTimeInterpreter must not return null time");
if (top < getHeight()) canvas.drawText(time, mTimeTextWidth + mHeaderColumnPadding, top + mTimeTextHeight, mTimeTextPaint);
}
}
private void drawHeaderRowAndEvents(Canvas canvas) {
mHeaderColumnWidth = mTimeTextWidth + mHeaderColumnPadding *2;
mWidthPerDay = getWidth() - mHeaderColumnWidth - mColumnGap * (mNumberOfVisibleDays - 1);
mWidthPerDay = mWidthPerDay/mNumberOfVisibleDays;
if (mAreDimensionsInvalid) {
mAreDimensionsInvalid = false;
if(mScrollToDay != null)
goToDate(mScrollToDay);
mAreDimensionsInvalid = false;
if(mScrollToHour >= 0)
goToHour(mScrollToHour);
mScrollToDay = null;
mScrollToHour = -1;
mAreDimensionsInvalid = false;
}
if (mIsFirstDraw){
mIsFirstDraw = false;
if(mNumberOfVisibleDays >= 7 && mToday.get(Calendar.DAY_OF_WEEK) != mFirstDayOfWeek) {
int difference = 7 + (mToday.get(Calendar.DAY_OF_WEEK) - mFirstDayOfWeek);
mCurrentOrigin.x += (mWidthPerDay + mColumnGap) * difference;
}
}
if (mCurrentScrollDirection == Direction.HORIZONTAL) mCurrentOrigin.x -= mDistanceX;
int leftDaysWithGaps = (int) -(Math.ceil(mCurrentOrigin.x / (mWidthPerDay + mColumnGap)));
float startFromPixel = mCurrentOrigin.x + (mWidthPerDay + mColumnGap) * leftDaysWithGaps +
mHeaderColumnWidth;
float startPixel = startFromPixel;
Calendar day = (Calendar) mToday.clone();
day.add(Calendar.HOUR, 6);
int lineCount = (int) ((getHeight() - mHeaderTextHeight - mHeaderRowPadding * 2 -
mHeaderMarginBottom) / mHourHeight) + 1;
lineCount = (lineCount) * (mNumberOfVisibleDays+1);
float[] hourLines = new float[lineCount * 4];
if (mEventRects != null) {
for (EventRect eventRect: mEventRects) {
eventRect.rectF = null;
}
}
mFirstVisibleDay = (Calendar) mToday.clone();
mFirstVisibleDay.add(Calendar.DATE, leftDaysWithGaps);
for (int dayNumber = leftDaysWithGaps + 1;
dayNumber <= leftDaysWithGaps + mNumberOfVisibleDays + 1;
dayNumber++) {
day = (Calendar) mToday.clone();
mLastVisibleDay = (Calendar) day.clone();
day.add(Calendar.DATE, dayNumber - 1);
mLastVisibleDay.add(Calendar.DATE, dayNumber - 2);
boolean sameDay = isSameDay(day, mToday);
if (mEventRects == null || mRefreshEvents || (dayNumber == leftDaysWithGaps + 1 && mFetchedMonths[1] != day.get(Calendar.MONTH)+1 && day.get(Calendar.DAY_OF_MONTH) == 15)) {
getMoreEvents(day);
mRefreshEvents = false;
}
float start = (startPixel < mHeaderColumnWidth ? mHeaderColumnWidth : startPixel);
if (mWidthPerDay + startPixel - start> 0)
canvas.drawRect(start, mHeaderTextHeight + mHeaderRowPadding * 2 + mTimeTextHeight/2 + mHeaderMarginBottom, startPixel + mWidthPerDay, getHeight(), sameDay ? mTodayBackgroundPaint : mDayBackgroundPaint);
int i = 0;
for (int hourNumber = 8; hourNumber < 21; hourNumber++) {
float top = mHeaderTextHeight + mHeaderRowPadding * 2 + mCurrentOrigin.y + mHourHeight * hourNumber + mTimeTextHeight/2 + mHeaderMarginBottom;
if (top > mHeaderTextHeight + mHeaderRowPadding * 2 + mTimeTextHeight/2 + mHeaderMarginBottom - mHourSeparatorHeight && top < getHeight() && startPixel + mWidthPerDay - start > 0){
hourLines[i * 4] = start;
hourLines[i * 4 + 1] = top;
hourLines[i * 4 + 2] = startPixel + mWidthPerDay;
hourLines[i * 4 + 3] = top;
i++;
}
}
canvas.drawLines(hourLines, mHourSeparatorPaint);
drawEvents(day, startPixel, canvas);
startPixel += mWidthPerDay + mColumnGap;
}
canvas.drawRect(0, 0, getWidth(), mHeaderTextHeight + mHeaderRowPadding * 2, mHeaderBackgroundPaint);
startPixel = startFromPixel;
for (int dayNumber=leftDaysWithGaps+1; dayNumber <= leftDaysWithGaps + mNumberOfVisibleDays + 1; dayNumber++) {
day = (Calendar) mToday.clone();
day.add(Calendar.DATE, dayNumber - 1);
boolean sameDay = isSameDay(day, mToday);
String dayLabel = getDateTimeInterpreter().interpretDate(day);
if (dayLabel == null)
throw new IllegalStateException("A DateTimeInterpreter must not return null date");
canvas.drawText(dayLabel, startPixel + mWidthPerDay / 2, mHeaderTextHeight + mHeaderRowPadding, sameDay ? mTodayHeaderTextPaint : mHeaderTextPaint);
startPixel += mWidthPerDay + mColumnGap;
}
}
private Calendar getTimeFromPoint(float x, float y){
int leftDaysWithGaps = (int) -(Math.ceil(mCurrentOrigin.x / (mWidthPerDay + mColumnGap)));
float startPixel = mCurrentOrigin.x + (mWidthPerDay + mColumnGap) * leftDaysWithGaps +
mHeaderColumnWidth;
for (int dayNumber = leftDaysWithGaps + 1;
dayNumber <= leftDaysWithGaps + mNumberOfVisibleDays + 1;
dayNumber++) {
float start = (startPixel < mHeaderColumnWidth ? mHeaderColumnWidth : startPixel);
if (mWidthPerDay + startPixel - start> 0
&& x>start && x<startPixel + mWidthPerDay){
Calendar day = (Calendar) mToday.clone();
day.add(Calendar.DATE, dayNumber - 1);
float pixelsFromZero = y - mCurrentOrigin.y - mHeaderTextHeight
- mHeaderRowPadding * 2 - mTimeTextHeight/2 - mHeaderMarginBottom;
int hour = (int)(pixelsFromZero / mHourHeight);
int minute = (int) (60 * (pixelsFromZero - hour * mHourHeight) / mHourHeight);
day.add(Calendar.HOUR, hour);
day.set(Calendar.MINUTE, minute);
return day;
}
startPixel += mWidthPerDay + mColumnGap;
}
return null;
}
private void drawEvents(Calendar date, float startFromPixel, Canvas canvas) {
if (mEventRects != null && mEventRects.size() > 0) {
for (int i = 0; i < mEventRects.size(); i++) {
if (isSameDay(mEventRects.get(i).event.getStartTime(), date)) {
float top = mHourHeight * 24 * mEventRects.get(i).top / 1440 + mCurrentOrigin.y + mHeaderTextHeight + mHeaderRowPadding * 2 + mHeaderMarginBottom + mTimeTextHeight/2 + mEventMarginVertical;
float originalTop = top;
if (top < mHeaderTextHeight + mHeaderRowPadding * 2 + mHeaderMarginBottom + mTimeTextHeight/2)
top = mHeaderTextHeight + mHeaderRowPadding * 2 + mHeaderMarginBottom + mTimeTextHeight/2;
float bottom = mEventRects.get(i).bottom;
bottom = mHourHeight * 24 * bottom / 1440 + mCurrentOrigin.y + mHeaderTextHeight + mHeaderRowPadding * 2 + mHeaderMarginBottom + mTimeTextHeight/2 - mEventMarginVertical;
float left = startFromPixel + mEventRects.get(i).left * mWidthPerDay;
if (left < startFromPixel)
left += mOverlappingEventGap;
float originalLeft = left;
float right = left + mEventRects.get(i).width * mWidthPerDay;
if (right < startFromPixel + mWidthPerDay)
right -= mOverlappingEventGap;
if (left < mHeaderColumnWidth) left = mHeaderColumnWidth;
RectF eventRectF = new RectF(left, top, right, bottom);
if (bottom > mHeaderTextHeight + mHeaderRowPadding * 2 + mHeaderMarginBottom + mTimeTextHeight/2 && left < right &&
eventRectF.right > mHeaderColumnWidth &&
eventRectF.left < getWidth() &&
eventRectF.bottom > mHeaderTextHeight + mHeaderRowPadding * 2 + mTimeTextHeight / 2 + mHeaderMarginBottom &&
eventRectF.top < getHeight() &&
left < right
) {
mEventRects.get(i).rectF = eventRectF;
mEventBackgroundPaint.setColor(mEventRects.get(i).event.getColor() == 0 ? mDefaultEventColor : mEventRects.get(i).event.getColor());
canvas.drawRect(mEventRects.get(i).rectF, mEventBackgroundPaint);
drawText(mEventRects.get(i).event.getName(), mEventRects.get(i).rectF, canvas, originalTop, originalLeft);
}
else
mEventRects.get(i).rectF = null;
}
}
}
}
private void drawText(String text, RectF rect, Canvas canvas, float originalTop, float originalLeft) {
if (rect.right - rect.left - mEventPadding * 2 < 0) return;
StaticLayout textLayout = new StaticLayout(text, mEventTextPaint, (int) (rect.right - originalLeft - mEventPadding * 2), Layout.Alignment.ALIGN_NORMAL, 1.0f, 0.0f, false);
int availableHeight = (int) (rect.bottom - originalTop - mEventPadding * 2);
int lineHeight = textLayout.getHeight() / textLayout.getLineCount();
if (lineHeight < availableHeight && textLayout.getHeight() > rect.height() - mEventPadding * 2) {
int lineCount = textLayout.getLineCount();
int availableLineCount = (int) Math.floor(lineCount * availableHeight / textLayout.getHeight());
float widthAvailable = (rect.right - originalLeft - mEventPadding * 2) * availableLineCount;
textLayout = new StaticLayout(TextUtils.ellipsize(text, mEventTextPaint, widthAvailable, TextUtils.TruncateAt.END), mEventTextPaint, (int) (rect.right - originalLeft - mEventPadding * 2), Layout.Alignment.ALIGN_NORMAL, 1.0f, 0.0f, false);
}
else if (lineHeight >= availableHeight) {
int width = (int) (rect.right - originalLeft - mEventPadding * 2);
textLayout = new StaticLayout(TextUtils.ellipsize(text, mEventTextPaint, width, TextUtils.TruncateAt.END), mEventTextPaint, width, Layout.Alignment.ALIGN_NORMAL, 1.0f, 1.0f, false);
}
canvas.save();
canvas.translate(originalLeft + mEventPadding, originalTop + mEventPadding);
textLayout.draw(canvas);
canvas.restore();
}
private class EventRect {
public WeekViewEvent event;
public WeekViewEvent originalEvent;
public RectF rectF;
public float left;
public float width;
public float top;
public float bottom;
public EventRect(WeekViewEvent event, WeekViewEvent originalEvent, RectF rectF) {
this.event = event;
this.rectF = rectF;
this.originalEvent = originalEvent;
}
}
private void getMoreEvents(Calendar day) {
deleteFarMonths(day);
if (mEventRects == null)
mEventRects = new ArrayList<EventRect>();
if (mMonthChangeListener == null && !isInEditMode())
throw new IllegalStateException("You must provide a MonthChangeListener");
if (mRefreshEvents) {
mEventRects.clear();
mFetchedMonths = new int[3];
}
int previousMonth = (day.get(Calendar.MONTH) == 0?12:day.get(Calendar.MONTH));
int nextMonth = (day.get(Calendar.MONTH)+2 == 13 ?1:day.get(Calendar.MONTH)+2);
int[] lastFetchedMonth = mFetchedMonths.clone();
if (mFetchedMonths[0] < 1 || mFetchedMonths[0] != previousMonth || mRefreshEvents) {
if (!containsValue(lastFetchedMonth, previousMonth) && !isInEditMode()){
List<WeekViewEvent> events = mMonthChangeListener.onMonthChange((previousMonth==12)?day.get(Calendar.YEAR)-1:day.get(Calendar.YEAR), previousMonth);
sortEvents(events);
for (WeekViewEvent event: events) {
cacheEvent(event);
}
}
mFetchedMonths[0] = previousMonth;
}
if (mFetchedMonths[1] < 1 || mFetchedMonths[1] != day.get(Calendar.MONTH)+1 || mRefreshEvents) {
if (!containsValue(lastFetchedMonth, day.get(Calendar.MONTH)+1) && !isInEditMode()) {
List<WeekViewEvent> events = mMonthChangeListener.onMonthChange(day.get(Calendar.YEAR), day.get(Calendar.MONTH) + 1);
sortEvents(events);
for (WeekViewEvent event : events) {
cacheEvent(event);
}
}
mFetchedMonths[1] = day.get(Calendar.MONTH)+1;
}
if (mFetchedMonths[2] < 1 || mFetchedMonths[2] != nextMonth || mRefreshEvents) {
if (!containsValue(lastFetchedMonth, nextMonth) && !isInEditMode()) {
List<WeekViewEvent> events = mMonthChangeListener.onMonthChange(nextMonth == 1 ? day.get(Calendar.YEAR) + 1 : day.get(Calendar.YEAR), nextMonth);
sortEvents(events);
for (WeekViewEvent event : events) {
cacheEvent(event);
}
}
mFetchedMonths[2] = nextMonth;
}
ArrayList<EventRect> tempEvents = new ArrayList<EventRect>(mEventRects);
mEventRects = new ArrayList<EventRect>();
Calendar dayCounter = (Calendar) day.clone();
dayCounter.add(Calendar.MONTH, -1);
dayCounter.set(Calendar.DAY_OF_MONTH, 1);
Calendar maxDay = (Calendar) day.clone();
maxDay.add(Calendar.MONTH, 1);
maxDay.set(Calendar.DAY_OF_MONTH, maxDay.getActualMaximum(Calendar.DAY_OF_MONTH));
while (dayCounter.getTimeInMillis() <= maxDay.getTimeInMillis()) {
ArrayList<EventRect> eventRects = new ArrayList<EventRect>();
for (EventRect eventRect : tempEvents) {
if (isSameDay(eventRect.event.getStartTime(), dayCounter))
eventRects.add(eventRect);
}
computePositionOfEvents(eventRects);
dayCounter.add(Calendar.DATE, 1);
}
}
private void cacheEvent(WeekViewEvent event) {
if (!isSameDay(event.getStartTime(), event.getEndTime())) {
Calendar endTime = (Calendar) event.getStartTime().clone();
endTime.set(Calendar.HOUR_OF_DAY, 23);
endTime.set(Calendar.MINUTE, 59);
Calendar startTime = (Calendar) event.getEndTime().clone();
startTime.set(Calendar.HOUR_OF_DAY, 0);
startTime.set(Calendar.MINUTE, 0);
WeekViewEvent event1 = new WeekViewEvent(event.getId(), event.getName(), event.getStartTime(), endTime);
event1.setColor(event.getColor());
WeekViewEvent event2 = new WeekViewEvent(event.getId(), event.getName(), startTime, event.getEndTime());
event2.setColor(event.getColor());
mEventRects.add(new EventRect(event1, event, null));
mEventRects.add(new EventRect(event2, event, null));
}
else
mEventRects.add(new EventRect(event, event, null));
}
private void sortEvents(List<WeekViewEvent> events) {
Collections.sort(events, new Comparator<WeekViewEvent>() {
@Override
public int compare(WeekViewEvent event1, WeekViewEvent event2) {
long start1 = event1.getStartTime().getTimeInMillis();
long start2 = event2.getStartTime().getTimeInMillis();
int comparator = start1 > start2 ? 1 : (start1 < start2 ? -1 : 0);
if (comparator == 0) {
long end1 = event1.getEndTime().getTimeInMillis();
long end2 = event2.getEndTime().getTimeInMillis();
comparator = end1 > end2 ? 1 : (end1 < end2 ? -1 : 0);
}
return comparator;
}
});
}
private void computePositionOfEvents(List<EventRect> eventRects) {
List<List<EventRect>> collisionGroups = new ArrayList<List<EventRect>>();
for (EventRect eventRect : eventRects) {
boolean isPlaced = false;
outerLoop:
for (List<EventRect> collisionGroup : collisionGroups) {
for (EventRect groupEvent : collisionGroup) {
if (isEventsCollide(groupEvent.event, eventRect.event)) {
collisionGroup.add(eventRect);
isPlaced = true;
break outerLoop;
}
}
}
if (!isPlaced) {
List<EventRect> newGroup = new ArrayList<EventRect>();
newGroup.add(eventRect);
collisionGroups.add(newGroup);
}
}
for (List<EventRect> collisionGroup : collisionGroups) {
expandEventsToMaxWidth(collisionGroup);
}
}
private void expandEventsToMaxWidth(List<EventRect> collisionGroup) {
List<List<EventRect>> columns = new ArrayList<List<EventRect>>();
columns.add(new ArrayList<EventRect>());
for (EventRect eventRect : collisionGroup) {
boolean isPlaced = false;
for (List<EventRect> column : columns) {
if (column.size() == 0) {
column.add(eventRect);
isPlaced = true;
}
else if (!isEventsCollide(eventRect.event, column.get(column.size()-1).event)) {
column.add(eventRect);
isPlaced = true;
break;
}
}
if (!isPlaced) {
List<EventRect> newColumn = new ArrayList<EventRect>();
newColumn.add(eventRect);
columns.add(newColumn);
}
}
int maxRowCount = columns.get(0).size();
for (int i = 0; i < maxRowCount; i++) {
float j = 0;
for (List<EventRect> column : columns) {
if (column.size() >= i+1) {
EventRect eventRect = column.get(i);
eventRect.width = 1f / columns.size();
eventRect.left = j / columns.size();
eventRect.top = eventRect.event.getStartTime().get(Calendar.HOUR_OF_DAY) * 60 + eventRect.event.getStartTime().get(Calendar.MINUTE);
eventRect.bottom = eventRect.event.getEndTime().get(Calendar.HOUR_OF_DAY) * 60 + eventRect.event.getEndTime().get(Calendar.MINUTE);
mEventRects.add(eventRect);
}
j++;
}
}
}
private boolean isEventsCollide(WeekViewEvent event1, WeekViewEvent event2) {
long start1 = event1.getStartTime().getTimeInMillis();
long end1 = event1.getEndTime().getTimeInMillis();
long start2 = event2.getStartTime().getTimeInMillis();
long end2 = event2.getEndTime().getTimeInMillis();
return !((start1 >= end2) || (end1 <= start2));
}
private boolean isTimeAfterOrEquals(Calendar time1, Calendar time2) {
return !(time1 == null || time2 == null) && time1.getTimeInMillis() >= time2.getTimeInMillis();
}
private void deleteFarMonths(Calendar currentDay) {
if (mEventRects == null) return;
Calendar nextMonth = (Calendar) currentDay.clone();
nextMonth.add(Calendar.MONTH, 1);
nextMonth.set(Calendar.DAY_OF_MONTH, nextMonth.getActualMaximum(Calendar.DAY_OF_MONTH));
nextMonth.set(Calendar.HOUR_OF_DAY, 12);
nextMonth.set(Calendar.MINUTE, 59);
nextMonth.set(Calendar.SECOND, 59);
Calendar prevMonth = (Calendar) currentDay.clone();
prevMonth.add(Calendar.MONTH, -1);
prevMonth.set(Calendar.DAY_OF_MONTH, 1);
prevMonth.set(Calendar.HOUR_OF_DAY, 0);
prevMonth.set(Calendar.MINUTE, 0);
prevMonth.set(Calendar.SECOND, 0);
List<EventRect> newEvents = new ArrayList<EventRect>();
for (EventRect eventRect : mEventRects) {
boolean isFarMonth = eventRect.event.getStartTime().getTimeInMillis() > nextMonth.getTimeInMillis() || eventRect.event.getEndTime().getTimeInMillis() < prevMonth.getTimeInMillis();
if (!isFarMonth) newEvents.add(eventRect);
}
mEventRects.clear();
mEventRects.addAll(newEvents);
}
@Override
public void invalidate() {
super.invalidate();
mAreDimensionsInvalid = true;
}
public DateTimeInterpreter getDateTimeInterpreter() {
if (mDateTimeInterpreter == null) {
mDateTimeInterpreter = new DateTimeInterpreter() {
@Override
public String interpretDate(Calendar date) {
SimpleDateFormat sdf;
sdf = mDayNameLength == LENGTH_SHORT ? new SimpleDateFormat("EEEEE") : new SimpleDateFormat("EEE");
try{
String dayName = sdf.format(date.getTime()).toUpperCase();
return String.format("%s %d/%02d", dayName, date.get(Calendar.MONTH) + 1, date.get(Calendar.DAY_OF_MONTH));
}catch (Exception e){
e.printStackTrace();
return "";
}
}
@Override
public String interpretTime(int hour) {
String amPm;
if (hour >= 0 && hour < 12) amPm = "AM";
else amPm = "PM";
if (hour == 0) hour = 12;
if (hour > 12) hour -= 12;
return String.format("%02d %s", hour, amPm);
}
};
}
return mDateTimeInterpreter;
}
public void setDateTimeInterpreter(DateTimeInterpreter dateTimeInterpreter){
this.mDateTimeInterpreter = dateTimeInterpreter;
}
public int getNumberOfVisibleDays() {
return mNumberOfVisibleDays;
}
public void setNumberOfVisibleDays(int numberOfVisibleDays) {
this.mNumberOfVisibleDays = numberOfVisibleDays;
mCurrentOrigin.x = 0;
mCurrentOrigin.y = 8;
invalidate();
}
public int getHourHeight() {
return mHourHeight;
}
public void setHourHeight(int hourHeight) {
mHourHeight = hourHeight;
invalidate();
}
public int getColumnGap() {
return mColumnGap;
}
public void setColumnGap(int columnGap) {
mColumnGap = columnGap;
invalidate();
}
public int getFirstDayOfWeek() {
return mFirstDayOfWeek;
}
public void setFirstDayOfWeek(int firstDayOfWeek) {
mFirstDayOfWeek = firstDayOfWeek;
invalidate();
}
public int getTextSize() {
return mTextSize;
}
public void setTextSize(int textSize) {
mTextSize = textSize;
mTodayHeaderTextPaint.setTextSize(mTextSize);
mHeaderTextPaint.setTextSize(mTextSize);
mTimeTextPaint.setTextSize(mTextSize);
invalidate();
}
public int getHeaderColumnPadding() {
return mHeaderColumnPadding;
}
public void setHeaderColumnPadding(int headerColumnPadding) {
mHeaderColumnPadding = headerColumnPadding;
invalidate();
}
public int getHeaderColumnTextColor() {
return mHeaderColumnTextColor;
}
public void setHeaderColumnTextColor(int headerColumnTextColor) {
mHeaderColumnTextColor = headerColumnTextColor;
invalidate();
}
public int getHeaderRowPadding() {
return mHeaderRowPadding;
}
public void setHeaderRowPadding(int headerRowPadding) {
mHeaderRowPadding = headerRowPadding;
invalidate();
}
public int getHeaderRowBackgroundColor() {
return mHeaderRowBackgroundColor;
}
public void setHeaderRowBackgroundColor(int headerRowBackgroundColor) {
mHeaderRowBackgroundColor = headerRowBackgroundColor;
invalidate();
}
public int getDayBackgroundColor() {
return mDayBackgroundColor;
}
public void setDayBackgroundColor(int dayBackgroundColor) {
mDayBackgroundColor = dayBackgroundColor;
invalidate();
}
public int getHourSeparatorColor() {
return mHourSeparatorColor;
}
public void setHourSeparatorColor(int hourSeparatorColor) {
mHourSeparatorColor = hourSeparatorColor;
invalidate();
}
public int getTodayBackgroundColor() {
return mTodayBackgroundColor;
}
public void setTodayBackgroundColor(int todayBackgroundColor) {
mTodayBackgroundColor = todayBackgroundColor;
invalidate();
}
public int getHourSeparatorHeight() {
return mHourSeparatorHeight;
}
public void setHourSeparatorHeight(int hourSeparatorHeight) {
mHourSeparatorHeight = hourSeparatorHeight;
invalidate();
}
public int getTodayHeaderTextColor() {
return mTodayHeaderTextColor;
}
public void setTodayHeaderTextColor(int todayHeaderTextColor) {
mTodayHeaderTextColor = todayHeaderTextColor;
invalidate();
}
public int getEventTextSize() {
return mEventTextSize;
}
public void setEventTextSize(int eventTextSize) {
mEventTextSize = eventTextSize;
mEventTextPaint.setTextSize(mEventTextSize);
invalidate();
}
public int getEventTextColor() {
return mEventTextColor;
}
public void setEventTextColor(int eventTextColor) {
mEventTextColor = eventTextColor;
invalidate();
}
public int getEventPadding() {
return mEventPadding;
}
public void setEventPadding(int eventPadding) {
mEventPadding = eventPadding;
invalidate();
}
public int getHeaderColumnBackgroundColor() {
return mHeaderColumnBackgroundColor;
}
public void setHeaderColumnBackgroundColor(int headerColumnBackgroundColor) {
mHeaderColumnBackgroundColor = headerColumnBackgroundColor;
invalidate();
}
public int getDefaultEventColor() {
return mDefaultEventColor;
}
public void setDefaultEventColor(int defaultEventColor) {
mDefaultEventColor = defaultEventColor;
invalidate();
}
@Deprecated
public int getDayNameLength() {
return mDayNameLength;
}
@Deprecated
public void setDayNameLength(int length) {
if (length != LENGTH_LONG && length != LENGTH_SHORT) {
throw new IllegalArgumentException("length parameter must be either LENGTH_LONG or LENGTH_SHORT");
}
this.mDayNameLength = length;
}
public int getOverlappingEventGap() {
return mOverlappingEventGap;
}
public void setOverlappingEventGap(int overlappingEventGap) {
this.mOverlappingEventGap = overlappingEventGap;
invalidate();
}
public int getEventMarginVertical() {
return mEventMarginVertical;
}
public void setEventMarginVertical(int eventMarginVertical) {
this.mEventMarginVertical = eventMarginVertical;
invalidate();
}
public Calendar getFirstVisibleDay() {
return mFirstVisibleDay;
}
public Calendar getLastVisibleDay() {
return mLastVisibleDay;
}
public float getXScrollingSpeed() {
return mXScrollingSpeed;
}
public void setXScrollingSpeed(float xScrollingSpeed) {
this.mXScrollingSpeed = xScrollingSpeed;
}
@Override
public boolean onTouchEvent(MotionEvent event) {
if (event.getAction() == MotionEvent.ACTION_UP) {
if (mCurrentScrollDirection == Direction.HORIZONTAL) {
float leftDays = Math.round(mCurrentOrigin.x / (mWidthPerDay + mColumnGap));
int nearestOrigin = (int) (mCurrentOrigin.x - leftDays * (mWidthPerDay+mColumnGap));
mStickyScroller.startScroll((int) mCurrentOrigin.x, 0, - nearestOrigin, 0);
ViewCompat.postInvalidateOnAnimation(WeekView.this);
}
mCurrentScrollDirection = Direction.NONE;
}
return mGestureDetector.onTouchEvent(event);
}
@Override
public void computeScroll() {
super.computeScroll();
if (mScroller.computeScrollOffset()) {
if (Math.abs(mScroller.getFinalX() - mScroller.getCurrX()) < mWidthPerDay + mColumnGap && Math.abs(mScroller.getFinalX() - mScroller.getStartX()) != 0) {
mScroller.forceFinished(true);
float leftDays = Math.round(mCurrentOrigin.x / (mWidthPerDay + mColumnGap));
if(mScroller.getFinalX() < mScroller.getCurrX())
leftDays--;
else
leftDays++;
int nearestOrigin = (int) (mCurrentOrigin.x - leftDays * (mWidthPerDay+mColumnGap));
mStickyScroller.startScroll((int) mCurrentOrigin.x, 0, - nearestOrigin, 0);
ViewCompat.postInvalidateOnAnimation(WeekView.this);
}
else {
if (mCurrentFlingDirection == Direction.VERTICAL) mCurrentOrigin.y = mScroller.getCurrY();
else mCurrentOrigin.x = mScroller.getCurrX();
ViewCompat.postInvalidateOnAnimation(this);
}
}
if (mStickyScroller.computeScrollOffset()) {
mCurrentOrigin.x = mStickyScroller.getCurrX();
ViewCompat.postInvalidateOnAnimation(this);
}
}
public void goToToday() {
Calendar today = Calendar.getInstance();
goToDate(today);
}
public void goToDate(Calendar date) {
mScroller.forceFinished(true);
date.set(Calendar.HOUR_OF_DAY, 8);
date.set(Calendar.MINUTE, 0);
date.set(Calendar.SECOND, 0);
date.set(Calendar.MILLISECOND, 0);
if(mAreDimensionsInvalid) {
mScrollToDay = date;
return;
}
mRefreshEvents = true;
Calendar today = Calendar.getInstance();
today.set(Calendar.HOUR_OF_DAY, 21);
today.set(Calendar.MINUTE, 0);
today.set(Calendar.SECOND, 0);
today.set(Calendar.MILLISECOND, 0);
int dateDifference = (int) ((date.getTimeInMillis() - today.getTimeInMillis()) / (1000 * 60 * 60 * 13));
mCurrentOrigin.x = - dateDifference * (mWidthPerDay + mColumnGap);
invalidate();
}
public void notifyDatasetChanged(){
mRefreshEvents = true;
invalidate();
}
public void goToHour(double hour){
int verticalOffset = (int) (mHourHeight * hour);
if (hour < 8)
verticalOffset = 8;
else if (hour > 21)
verticalOffset = mHourHeight * 21;
if (mAreDimensionsInvalid) {
mScrollToHour = hour;
return;
} else if (verticalOffset > mHourHeight * 21 - getHeight() + mHeaderTextHeight + mHeaderRowPadding * 2 + mHeaderMarginBottom)
verticalOffset = (int)(mHourHeight * 21 - getHeight() + mHeaderTextHeight + mHeaderRowPadding * 2 + mHeaderMarginBottom);
mCurrentOrigin.y = -verticalOffset;
invalidate();
}
}
Allegati:
